Impact Crusher

Processing ability:

10–600 t/h

Brief introduction:

PF Series Impact Crusher is mainly used in secondary crushing of the crushing line. Our impact crusher has the special structure design.

Send us at baichenruitong@163.com

Application
Features
Working principle
Technical data
Related Production
Sent Inquiry

Applications:

pebble, limestone, granite, basalt, diabase, andesite, etc

Features:

1.Advanced processing technology,high quality plates and ware parts are the basis parts to improve the production efficiency.
2. Two-cavity impact crusher can becomes three-cavity machine by adding grinding racks.

Working principle:

Impact crusher crushes material by striking energy.when it works,the motor drives the rotor rotate at a high speed .When the material get into the blow bar working area,they will be stroke by the blow bar and thrown to the impact devices around the rotor.The material will come out from the discharge hole until they are crushed to the required size. The clearance between the impact rack and the rotor can adjust the size and shape of the end product.

Technical data:

Type	Feeding Hole Dimension(mm)	Maximum Feedstock Granularity (mm)	Rotor Dimension (mm*mm) Handling	Ability(t/h)	Power(kw)	Overall Dimension (mmmmmm)
PF-1007	400X730	250	Φ1000X700	10-50	45/55	244015802672
PF-1010	400X1080	250	Φ1035X1050	50-80	55/90	228018042389
PF-1210	400X1080	350	Φ1250X1050	70-120	110	316520272729
PF-1214	400X1430	350	Φ1250X1400	95-145	132/160	257124032705
PF-1315	860X1520	350	Φ1320X1500	150-200	220	315426952613
PF-1320	860X2030	500	Φ1320X1200	200-280	315	332032182613
PF-1416	1052X1652	500	Φ1420X1600	280-350	355	340528132713
PF-1520	2040X1315	700	Φ1512X2000	350-450	400/450	413834223649
PF-1620	2040X1315	700	Φ1612X2000	400-600	500	423635723735
